Structure characteristics of cheese melting machine:
Adopt structure of internal tank and external package, with heat preservation materials inside.
Materials are all sanitary stainless steel.
Humanized structure design and easy to operate.
Transition area of interior wall on tank adopts arc for transition to ensure no dead corner of
sanitation.
Applicable range of cheese making machine:
Used as blending tank, mixing tank, preparation tank, fermentation tank, disinfection tank and ageing tank etc.
Ideal in fields such as food, dairy products, fruit juice beverages, pharmacy, chemical industry and biological engineering etc.
Configuration of cheese making tank:
Quick open flat cover.
Various types of CIF cleaners.
Fly and insect resistant sanitary breathing cover. (according to customer requirements)
Adjustable triangular bracket. (according to customer requirements)
Dismountable materials input pipe assembly.
Thermometer (according to customer requirements).
Ladder (according to customer requirements).
Vertical blender (paddle type or fame type are available if customer require).
Jacket (miller board, hollow jacket or coil pipe jacket are available according to customer requirements).
Liquid level meter and level controller (according to customer requirements).
Eddy-proof board. (according to customer requirements)
Technical parameters of cheese machine/ cheese making machine/ cheese melting machine:
| Effective volume | Dimension of tank | Total height | Diameter of inlet&outlet | Heat preservation layer |
| (L) | (mm) | (mm) | (mm) | (mm) |
| 500 | 840*1000 | 2250 | 38 | 60 |
| 600 | 920*1000 | 2300 | 38 | 60 |
| 700 | 990*1000 | 2300 | 38 | 60 |
| 800 | 950*1220 | 2500 | 38 | 60 |
| 900 | 1010*1220 | 2500 | 38 | 60 |
| 1000 | 1060*1500 | 2850 | 51 | 60 |
| 1500 | 1160*1500 | 2850 | 51 | 60 |
| 2000 | 1340*1500 | 2900 | 51 | 60 |
| 3000 | 1410*2000 | 3400 | 51 | 60 |
| 4000 | 1620*2000 | 3450 | 51 | 60 |
| 5000 | 1810*2000 | 3500 | 51 | 60 |
| 6000 | 1980*2000 | 3550 | 51 | 60 |
| 7000 | 1930*2440 | 4000 | 51 | 60 |
| 8000 | 2060*2440 | 4000 | 51 | 60 |
| 9000 | 2180*2440 | 4050 | 51 | 60 |
| 10000 | 2300*2440 | 4050 | 51 | 60 |
| 12000 | 2270*3000 | 4600 | 51 | 60 |
| 15000 | 2530*3000 | 4700 | 51 | 60 |
| 20000 | 2640*3660 | 5400 | 51 | 60 |
More specification for reference:
